2026 Kioti DK5520
Get in Touch
Description
2026 Kioti DK5520
DK5520 Compact Tractor
The KIOTI DK5520 compact tractor is designed for those who demand premier performance in a compact tractor. Offering mid & rear PTO, independent PTO, and a category 2, 3-point hitch.
Features May Include:
Convenience Features
- A deluxe suspension seat, PTO cruise, high ground clearance, power steering, tilt steering wheel, center marker, projection light for better night vision, and a one piece engine panel to check service points with ease.
Safety
- Wet disc brakes, a sturdy ROPS or Cab, and a secure seatbelt keep you safe. Headlights, safety lights, and a rear work light lets you see attachments and drawbars clearly, even in low-light conditions.
Attractive Options
- Dress up your tractor with impressive options. Swap standard tires for turf, industrial, or R14 tires. Add a fuel heater kit, 2nd remote hydraulic valve, or bluetooth speaker kit for comfort and convenience.
Rugged Performance
- Dependable, liquid-cooled KIOTI 3-cylinder diesel engine hums with fuel efficiency, ready to take on demanding jobs all day long. Engage the rear differential lock for unflinching traction, then command implements with the push-button hydraulic PTO.
Info
Industry
Agriculture
Make
Kioti
Model
DK5520
Trim
Base
Year
2026
MSRP
N/A
Category
Tractor
Subcategory
Utility
Specs
Tires
Agricultural - Front: 8-16 | Agricultural - Rear: 13.6-24 | Industrial - Front: 10-16.5 | Industrial - Rear: 14.9-24 | R14 - Front: 10-16.5 | R14 - Rear: 320/85R24 | Turf - Front: 29-12.5-15 | Turf - Rear: 21.5-16.1
Warranty
Non-Commercial Application: 24 Months, Coverage: Parts & Labor | Rental and Commercial Application: The first to occur of 24 months of 1500 hours, Coverage: Parts & Labor
Engine
Model: 3HT-TM4B | Engine Manufacturer: KIOTI
Power/Horsepower
55 hp (41 kW)
Displacement
111.40 cu. in. (1,826 cc)
RPM
2,600 rpm
Fuel Capacity
11.90 gal (45 L)
Transmission
Manual: Synchro Shuttle | Shuttle: Dry Single Stage | Main Gear: Dry Single Stage | Travel Speeds Forward: 4 | Travel Speeds Reverse: 2 | Travel Speeds Minimum Speed: 2.08 mph (3.35 km/h) | Travel Speeds Maximum Speed: 26.90 mph (43.30 km/h) | Travel Speeds Min Reverse Speed: 2.03 mph (3.26 km/h) | Travel Speeds Max Reverse Speed: 26.20 mph (42.20 km/h)
PTO Type
Independent | PTO Power: 45.60 hp (34 kW) | Rear Speed: 540 | Mid Speed: 2,000
Brakes
Wet Multi Disc
Clutch
Dry Single Stage
Steering
Hydrostatic Power Steering
Notes
Hydraulics - Pump: Gear | Hydraulics - Pump Capacity: 16.50 gpm (62.40 lpm) | Hitch - Type: Three Point | Hitch - Category: Category 1 | Hitch - Control Type: Position
Load Capacity
Hydraulics - Lift Capacity: 2,716 lb (1,232 kg) | Hitch - Lift Capacity: 2,716 lb (1,232 kg)
Fuel Type
Diesel
Length
With Hitch: 124.80 in (3,170 mm)
Width
62.80 in (1,596 mm) | Front Tread: 49.40 in (1,254 mm) | Rear Tread: 49.30 in (1,251 mm)
Wheelbase
Length: 71.30 in (1,810 mm)
Ground Clearance
14.50 in (368 mm)
Turning Radius
8.56 ft (2.60 m)
Weight
3,373 lb (1,530 kg)
Height
96.80 in (2,458 mm)
